Design Features:
√ The 4/3 C TH slurry pump frame plates have replaceable wear-resistant metal liners, impellers & volute liners are made of wear-resistant metal(such as A05, A49,and other high chrome metal).

√ The 4/3 C TH slurry pump bearing assembly use cylindrical structure, adjusting the space between impeller& front liner easily, being removed completely when being repaired. Grease lubrication.

√ The 4/3 C TH slurry pump shaft seal could use the packing seal, expeller seal and mechanical seal. One pump also can be use packing seal with expeller seal together.

√ The discharge outlet can be positioned at intervals of 45 degrees by request and oriented to any 8 positions to suit installations and applications.

√ The 4/3 C TH slurry pump can be installed in multistage series to meet the delivery for long distance.

√ The 4/3 C TH slurry pump drive types, such as direct coupling drive (DC), V belt drive (CR, CV, ZV) etc.

RT^® 4/3 C TH Slurry Pump Performance Parameters:


Model	Max. Power (kw)	Materials		Clear Water Performance					Impeller Vane No.
		Liner	Impeller	Capacity Q (m3/h)	Head H (m)	Speed n (rpm)	Eff. η (%)	NPSH (m)
4/3C-TH	30	Metal	Metal	86.4~198	9~52	1000~2200	71	4~6	5


RT® 4/3 C TH Slurry Pumps Applications:
Transfer of abrasives and high density slurries in:
• Mining
• Metallurgical Processing
• Civil Construction
• Heavy Industry
• Processing



Note:

* RT® is a registered trademark and does not represent or is not in any way affiliated with Warman® of Weir Minerals Group. All names, numbers, symbols and descriptions are used for reference purpose only and do not imply that any pumps or parts listed is the product of Warman Pumps.

* RT® 4/3 C TH slurry pumps and spares are only interchangeable with Warman® 4/3 C AH slurry pumps and spares.

* This document is the property of RT® Pump and can be neither reproduced nor disclosed to a third party without a written authorization.
