Design Features:
√ Heavy duty construction with through-bolt design provides ease of maintenance and minimal downtime

√ Ductile iron fully lined casing provides durability, strength, safety, and long service life

√ Large diameter, slow turning, high efficiency slurry pump impellers designed to achieve maximum wear life and low operating costs

√ Large, open internal passages designed to reduce internal velocities, maximise wear life and lower operating costs

√ Thick elastomer or alloy bolt-in liners provide superior corrosion resistance plus offer ease of liner change-out and interchangeability to reduce overall maintenance costs and maximise wear life

√ Minimal shaft/impeller overhang reduces shaft deflection and increases packing life

√ Cartridge-style bearing assembly allows for maintenance in a clean environment without removal of the slurry pump, resulting in reliable operation and prolonged bearing life

√ Grease or oil lubrication bearing assembly options offer ease of maintenance and reduced downtime

√ Optional dry running shaft seal reduces or eliminates flush water requirements

√ Effective expeller prolongs packing life while reducing or eliminating flush water requirement

 Interchangeability of seal arrangements – full flush, low flow, centrifugal, or mechanical seals may be fitted to any sized slurry pump

RT® 16/14 TU TH Slurry Pump Performance Parameters:

Model	Max. Power (kw)	Materials		Clear Water Performance					Impeller Vane No.
		Liner	Impeller	Capacity Q (m3/h)	Head H (m)	Speed n (rpm)	Eff. η (%)	NPSH (m)
16/14TU-TH	1200	M	M	1368~3060	11~63	250~550	79	4~10	5

RT® 16/14 TU TH Slurry Pumps Applications:

40-80% for higher density, strong abrasive slurries
40-100% for medium density, medium abrasive slurries
40-120% for lower density, lower abrasive slurries



Note:

* RT® is a registered trademark and does not represent or is not in any way affiliated with Warman® of Weir Minerals Group. All names, numbers, symbols and descriptions are used for reference purpose only and do not imply that any pumps or parts listed is the product of Warman Pumps.

* RT® 16/14 TU TH slurry pumps and spares are only interchangeable with Warman® 16/14 TU AH slurry pumps and spares.
